The fixed patient transfer unit (PTU) with window “Gamma/1”, release of 2013, has been conceived using the experience and know-how of OPT, gained in more than 90 years’ knowledge of the medical field. The goal of this device is to maintain the aseptic condition of the OR.
The PTU with window “Gamma/1” is used for transferring the patient from the operating table to the hospital bed without having the personnel pass constantly from the septic to the aseptic area with clear advantages in terms of hygiene. The window allows the PTU to divide the aseptic area from the septic one before and after the patient’s transferring.
safe and stable
to be used universally
user friendly
hygienic
functional
PTU has a patient recognition system (and/or recognition of any obstacles) which avoids the contact with the window during the transferring of patients.
The patient is protected by a couple of IR sensors located on the side of the transfer top, which make an anti-falling barrier in case of user’s mistake.
The system makes it possible to speed up the transfer top movement by pressing the button on the remote control so to reduce transferring times.
In case of network failure, emergency, motor failure and/or absence of electricity it is possible to manually translate the PTU transfer top by using the emergency crank-handle device.
The PTU has a sensor kit for the recognition of trolleys for carrying operating table tops. The kit is installed on two sides of the PTU window and recognizes the presence of a table top or of a stretcher and it blocks the down movement of the transfer top after a certain time.
The PTU can be equipped with a heated table top for a better patient comfort.
Two infrared remote controls (one in the aseptic area and the other one in the septic one) to activate all the electro-mechanical movements.
The PTU “Gamma/1” makes through two wired hand remote controls (one in the aseptic area, the other one in the septic one) the following electro-mechanical movements:
